Housing:
Self-supporting construction made of texture corrosion resistance electro galvanize steel sheet.
Base Frame:
Structural iron with steel/E.G.Legs.
Condenser Element:
High efficiency finned coil made of 3/8"Ø, 1/2"Ø and 5/8"Ø copper tube/inner grooved tube mechanically bonded into corrugated sine wave aluminum fins with full depth drawn collars.
Design Variations:
Multiple circuits for higher efficiency.
Pressure Test:
All coils are pressure tested on 350-400 PSIG
Refrigerant:
Suitable for R22, R134a and R404a/R507
Extend Supply:
Base frame, housing, condenser element dehydrated, with connections for one refrigeration circuit; built-in maintenance-free external rotor motor, axial fans, connecting copper pipes.
Optional Features:
